Excel Histogram: show how values are spread across ranges

A column chart compares categories. A histogram shows how numbers are spread: how many students scored 40–60, 60–80, 80–100.

The built-in histogram (Excel 2016 and later)

1. Select the column of numbers (just one column).
2. Insert › Insert Statistic Chart › Histogram.

Excel picks the bins for you.

Set your own bins

Right-click the horizontal axis › Format Axis:

• Bin width — e.g. 10 for bins of 10 marks.
• Number of bins — e.g. 5.
• Overflow bin — everything above 90 in one bar.
• Underflow bin — everything below 40 in one bar.

Round, sensible bins (10, 20, 50, 100) make the chart easier to read.

With a formula: FREQUENCY

Upper limits of each bin in D2:D6 (50, 60, 70, 80, 100). Select E2:E7 and enter:

=FREQUENCY(B2:B200,D2:D6)

In Excel 365 it spills on its own; in older versions press Ctrl+Shift+Enter. The extra last cell counts values above the top limit. Plot the counts as a column chart with gap width 0.

Or with COUNTIFS

Count between two limits: =COUNTIFS(B:B,">="&C2,B:B,"<"&D2). See COUNTIFS.

Reading it

• One hump in the middle — most values are typical.
• Long tail to the right — a few very large values (common with sales or salaries).
• Two humps — you probably have two groups mixed together.
